• Body-side paint stripe
• Luggage rack
• Chrome front bumper
• Beige rear step bumper
• Beige body-side/wheellip moldings
• Argent grille
• Illuminated beige running boards
• "Blocker Beam" front bumper supplement
• Aero halogen headlights
• Black pwr heated mirrors
• Privacy glass
• Pwr rear quarter windows
• Speed-sensitive intermittent windshield wipers
• Rear window intermittent wiper w/washer
• Color-keyed door handles
• Reverse sensing system
• Tri-panel rear door-inc: top half liftgate, 2 lower swing-out cargo doors

• Leather front captains chairs-inc: 6-way pwr driver seat
• Leather 2nd row reclining 60/40 split bench seat-inc: dual tip/slide feature center armrests, cup holders
• Leather 3rd row 3-passenger removable fold-flat bench seat w/rollers
• Floor console w/storage bin
• Color-keyed 12 oz carpet
• 1st/2nd color-keyed carpeted floor mats
• Leather steering wheel
• Tilt steering column
• Instrumentation-inc: tachometer, trip odometer, voltmeter, oil pressure/ coolant temp/fuel gauges
• Speed control
• Pwr windows w/driver one-touch-down
• Pwr door locks
• Remote keyless entry-inc: 2-transmitters, door keypad
• Passive anti-theft system
• Manual front/rear air conditioning
• Rear floor heat ducts
• Rear window defroster
• Premium electronic AM/FM stereo w/compact disc/cassette-inc: 80-watt amp
• Rear seat audio controls
• Glove box
• (10) cup holders
• Cigarette lighter
• Color-keyed instrument panel
• (5) auxiliary pwr points
• Molded door trim panel-inc: soft armrest, upper woodgrain insert, dual map pockets, lower carpet
• Electrochromatic rear view mirror
• Overhead console-inc: trip computer, pwr rear quarter window controls
• Molded cloth headliner
• Front/rear assist handles
• Color-keyed sun visors-inc: illuminated vanity mirrors, secondary sun blade
• Dual coat hooks over 2nd row doors
• Dual coat hooks in cargo area
• Lights-inc: underhood, glove box, front dome/map, front door courtesy, overhead rear cargo, 2nd/3rd row map lights
• Cargo net

• Driver & front passenger airbags
• 4-wheel anti-lock braking system
• 1st/2nd row color-keyed safety belts w/adjustable D-rings
• Child-proof rear door locks
• "Blocker Beam" front bumper supplement

7.3L (444) DI V8 TURBO-DIESEL ENGINE

• engine block heater
• dual 750-CCA batteries

• 3.73 Axle Ratio
• Premium Aluminum Wheels
• Leather Surface Captain's Chairs
• 4 Speakers
• Driver's Seat Mounted Armrest
• Front Center Armrest w/Storage
• Compass
• Speed-Sensitive Wipers
• Auto-dimming Rear-View mirror
• Front beverage holders
• Variably intermittent wipers
• Trip computer
• Tilt steering wheel
• Split folding rear seat
• Speed control
• Remote keyless entry
• Rear window wiper
• Rear window defroster
• Rear seat center armrest
• Rear reading lights
• Rear audio controls
• Rear air conditioning
• Power windows
• Power steering
• Power driver seat
• Power door mirrors
• Passenger vanity mirror
• Passenger seat mounted armrest
• Passenger door bin
• Overhead console
• Outside temperature display
• Leather steering wheel
• Illuminated running boards
• Illuminated entry
• Heated door mirrors
• Front wheel independent suspension
• Front reading lights
• Front anti-roll bar
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• CD player
• Bumpers: chrome
• Alloy wheels
• AM/FM radio
• ABS brakes
• 3rd row seats: bench
• Voltmeter
• Tachometer
• Roof rack
• Rear Parking Sensors
• Front Bucket Seats
• Cassette
• Air Conditioning
• 4-Wheel Disc Brakes

• Vehicle
• Rear Door Type: Tri-Panel
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 130
• Cooling System
• Total Cooling System Capacity (qts): 30.6
• Total Cooling System Capacity (qts): 26.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4400
• Gross Axle Wt Rating - Rear (lbs): 5250
• Curb Weight - Front (lbs): 3782
• Curb Weight - Front (lbs): 3262
• Curb Weight - Rear (lbs): 3415
• Curb Weight - Rear (lbs): 3388
• Gross Vehicle Weight Rating Cap (lbs): 8900
• Gross Vehicle Weight Rating Cap (lbs): 8600
• Gross Combined Wt Rating (lbs): 18000
• Gross Combined Wt Rating (lbs): 13000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: Multi-Stage Leaf
• Spring Capacity - Front (lbs): 3950
• Spring Capacity - Rear (lbs): 5250
• Axle Type - Front: Ford Twin I-Beam
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4850
• Axle Capacity - Rear (lbs): 6830
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 1.375
• Shock Absorber Diameter - Rear (mm): 1.375
• Stabilizer Bar Diameter - Front (in): 1.36
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.1 x - TBD -
• Rear Brake Rotor Diam x Thickness (in): 13.2 x - TBD -
• Tires
• Front Tire Order Code: T48
• Rear Tire Order Code: T48
• Spare Tire Order Code: T48
• Front Tire Size: LT265/75R16D
• Rear Tire Size: LT265/75R16D
• Spare Tire Size: LT265/75R16D
• Front Tire Capacity (lbs): 3000
• Rear Tire Capacity (lbs): 3000
• Spare Tire Capacity (lbs): 3000
• Revolutions/Mile @ 45 mph - Front: 658
• Revolutions/Mile @ 45 mph - Rear: 658
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 7.0
• Rear Wheel Size (in): 16 x 7.0
• Spare Wheel Size (in): - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 17
• Turning Diameter - Curb to Curb (ft): 46.8
• Turning Diameter - Wall to Wall (ft): 49.6
• Frame
• Frame Type: Boxed w/Single Channel
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 44
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 137.0
• Length, Overall w/rear bumper (in): 226.7
• Width, Max w/o mirrors (in): 80.0
• Height, Overall (in): 76.5
• Overhang, Front (in): 37.4
• Overhang, Rear w/bumper (in): 52.3
• Ground to Top of Load Floor (in): - TBD -
• Ground Clearance, Front (in): 8.5
• Ground Clearance, Rear (in): 8.5
• Rear Door Opening Height (in): 38.1
• Rear Door Opening Width (in): 55.8
• Step Up Height - Front (in): - TBD -
• Step Up Height - Side (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 165.0
• Cargo Area Length @ Floor to Seat 2 (in): 108.3
• Cargo Area Length @ Floor to Seat 3 (in): 48.6
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 52.5
• Cargo Box (Area) Height (in): - TBD -
• Cargo Volume to Seat 1 (ft³): 146.4
• Cargo Volume to Seat 2 (ft³): 100.7
• Cargo Volume to Seat 3 (ft³): 48.6
• Interior Dimensions
• Passenger Capacity: 8
• Front Head Room (in): 41.0
• Front Leg Room (in): 42.3
• Front Shoulder Room (in): 68.3
• Front Hip Room (in): 67.5
• Second Head Room (in): 41.1
• Second Leg Room (in): 40.5
• Second Shoulder Room (in): 67.0
• Second Hip Room (in): 66.9
• Third Head Room (in): 38.6
• Third Leg Room (in): 39.0
• Third Shoulder Room (in): 64.9
• Third Hip Room (in): 52.5
• Summary
• Vehicle Name: Ford Excursion
• Body Style: 4 door
• Body Code: 137" WB
